3,000 Litre Jacketed Stainless Mixing Vessel

3,000 Litre Jacketed Stainless Mixing Vessel

Stock #2722
1 in stock

Specification

Capacity: 3000 litres
Condition Used
Material Stainless Steel

Description

Used 3,000 Litre Jacketed Stainless Mixing Vessel. Material of construction stainless steel. Orientation vertical, cylindrical, flat top, coned base, supported on legs. Dimensions 1325mm diameter, 2150mm on the straight, 250mm bottom cone, overall height excluding drive 3400mm. Vessel is fitted with a top centre mounted twin flight 4 bladed turbine agitator powered by a 7.5kw Gamak Electric Motor, 3ph, 50hz, 380-415v, 1430rpm. Vessel is fitted with a hot oil jacket and is insulated and clad in stainless steel. Previously used to mix cosmetic products.
