7,000 Litre Jacketed Mixing Vessel #2480
Used 7,000 Litre Jacketed Mixing Vessel, manufactured by Chemplant, 1982. Material of construction stainless steel. Orientation vertical, cylindrical, dished bottom, flat bolted top. Vessel is supported on 4 steel legs. Dimensions 2000mm internal diameter, 2200mm overall diameter, 2200mm on the straight. Vessel has stainless steel dimple jacket with a working pressure of 90 psi. Vessel base and 3/4 of body are insulated and clad. Vessel has a steel mounting bridge upon which two agitator drives sit. A top mounted Greaves high shear batch mixer powered by a 18.5kw electric motor and a twin flighted turbine agitator powered by a 7.5kw electric motor.
