Outotec Larox Automatic Pressure Filter PF12.5

Outotec Larox Automatic Pressure Filter PF12.5

Stock #1933
Out of stock

Contact us about your equipment needs


Capacity: 12.6 m2
Condition Used
Manufacturer Outotec Larox
Build Year 1996
Model/Type PF12.5


Used 12.6m2 Automatic Pressure Filter, manufactured by Outotec Larox, 1997, type PF12.5 B2M, Serial No. 4095/511. Filtration area 12.6m2. Complete program, filters with cake washing (six stages: filtering, pressing I, washing, pressing II, drying, cake discharge). Wetted parts constructed of 316L stainless steel. 8 off Filter plates, size 900mm x 1750mm x 60mm. Filter cloth 1050mm width, 27500mm length. Main dimensions of machine 4050mm Length x 2975mm width x 2930mm height.  Weight approx 18000kgs. The filter is complete with pipeline connections, manifold hosing, drip trays, cake chutes, control valves and PLC control panel. The PLC control panel was upgraded to a touch screen version in 2006. The pressing water system is not included. Larox filter also comes complete with new spares including new electric motor, new filter cloth, four new stainless steel filter plates (2 total), manufacturers technical dossiers and maintenance records. The pressure filter was previously used on a chemical process (zinc omadine).

Dimension (LxWxH): 4050 x 2975 x 2930 cm
Weight (kg): 18000
